British PERKINS ENGINE COMPANY LIMITED created by entrepreneur Frank•Perkins in British Peterborough in 1932，whichis one of the world’s leading manufacturers of engine.Service Network covers more than 180 countries and areas, alloutlets upholdthe most stringent standards, to assure that the customers in every corner ofthe world can obtain the best qualityof service. Till now, their 400 seriesand some of the 1100 series engine made in Wuxi China, all the rest models areall made in UK.
| GEUSETS | Specification | General specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50HZ 230v/400v | ||||||||||||
| KVA/KW Cos 0.8 |
Cons 100% L/h |
Engine model | Max output | Cyl. |
displa cement |
Gov. | Open type dimension &weight | |||||
| ESP | PRP | KW | L | Dimenssion | weight |
PDF download |
||||||
| LxWxH(mm) | kg | |||||||||||
| ENCP10-3 | 10/8 | 9/7 | 3 | 403D-11G | 9.5 | 3 | 1.13 | M | 1320×700×1160 | 440 |
|
|
| ENCP14-3 | 14/11 | 13/10 | 3.7 | 403D-15G | 13.5 | 3 | 1.5 | M | 1320×700×1160 | 520 |
|
|
| ENCP17-3 | 22/18 | 20/16 | 5.3 | 404D-22G | 22.1 | 4 | 2.2 | M | 1320×700×1160 | 550 |
 |
|
| ENCP22-3 | 27/22 | 25/20 | 6.3 | 404D-22TG | 26.1 | 4 | 2.2 | M | 1320×700×1160 | 570 |
|
|
| ENCP33-3 | 33/26 | 30/24 | 7.1 | 1103A-33G | 31 | 3 | 3.3 | M | 1650×770×1254 | 730 |
|
|
| ENCP50-3 | 50/40 | 45/36 | 13.9 | 1103A-33TG1 | 60.5 | 3 | 3.3 | M | 1650×770×1254 | 835 |
|
|
| ENCP65-3 | 65/53 | 60/48 | 17 | 1103A-33TG2 | 80.7 | 3 | 3.3 | M | 1650×770×1254 | 935 |
|
|
| ENCP72-3 | 72/57 | 65/52 | 18.7 | 1104A-44TG1 | 65.6 | 4 | 4.4 | M | 1935×815×1300 | 1103 |
|
|
| ENCP88-3 | 88/70 | 80/64 | 21 | 1104A-44TG2 | 80.7 | 4 | 4.4 | M | 1935×815×1300 | 1173 |
|
|
| ENCP110-3 | 110/88 | 100/80 | 23 | 1104C-44TAG2 | 103 | 4 | 4.4 | E | 1935×815×1300 | 1253 |
|
|
| ENCP150-3 | 150/120 | 135/108 | 37 | 1106A-70TAG1 | 145.9 | 6 | 7 | M | 2550×950×1535 | 1660 |
|
|
| ENCP165-3 | 165/132 | 150/120 | 41 | 1106A-70TAG2 | 153 | 6 | 7 | M | 2550×950×1535 | 1760 |
|
|
| ENCP200-3 | 200/160 | 180/144 | 41.6 | 1106A-70TAG3 | 186.3 | 6 | 7 | M | 2550×950×1535 | 1800 |
|
|
| ENCP220-3 | 220/176 | 200/160 | 47 | 1106A-70TAG4 | 196.3 | 6 | 7 | M | 2550×950×1535 | 1850 |
|
|
| ENCP250-3 | 250/200 | 225/180 | 48.5 | 1306A-E87TAG4 | 224 | 6 | 8.7 | ECM | 2550×950×1680 | 1879 |
|
|
| ENCP275-3 | 275/220 | 250/200 | 49.7 | 1306A-E87TAG6 | 246 | 6 | 8.7 | ECM | 2550×950×1680 | 2000 |
|
|
| ENCP300-3 | 300/240 | 275/220 | 56 | 1606A-E93TAG4 | 271 | 6 | 9.3 | ECM | 2750×1150×1670 | 2200 |
|
|
| ENCP330-3 | 330/264 | 300/240 | 61 | 1606A-E93TAG5 | 297 | 6 | 9.3 | ECM | 2750×11150×1670 | 2400 |
|
|
| ENCP385-3 | 385/308 | 350/280 | 75 | 2206C-E13TAG2 | 368.4 | 6 | 12.5 | ECM | 3440×1150×1990 | 3049 |
|
|
| ENCP440-3 | 440/352 | 400/320 | 81 | 2206C-E13TAG3 | 412.5 | 6 | 12.5 | ECM | 3440×1150×1990 | 3345 |
|
|
| ENCP500-3 | 500/400 | 455/364 | 99 | 2506C-E15TAG1 | 451 | 6 | 15.2 | ECM | 3440×1150×1990 | 3693 |
|
|
| ENCP550-3 | 550/440 | 500/400 | 106 | 2506C-E15TAG2 | 495 | 6 | 15.1 | ECM | 3440×1150×1990 | 3793 |
|
|
| ENCP660-3 | 660/528 | 600/480 | 110 | 2806C-E18TAG1A | 583.8 | 6 | 18.1 | ECM | 3400×1540×1958 | 4239 |
|
|
| ENCP700-3 | 700/560 | 650/520 | 123 | 2806A-E18TAG2 | 628 | 6 | 18.1 | ECM | 3400×1540×1958 | 4330 |
|
|
| ENCP825-3 | 825/660 | 750/600 | 168.9 | 4006-23TAG2A | 717 | 6 | 22.9 | E | 4285×1720×2218 | 5295 |
|
|
| ENCP880-3 | 880/704 | 800/640 | 170.7 | 4006-23TAG3A | 786 | 6 | 22.9 | E | 4285×1720×2218 | 5495 |
|
|
| ENCP1100-3 | 1100/880 | 1000/800 | 220 | 4008TAG2A | 985 | 8 | 30.5 | E | 4690×2070×2395 | 5600 |
|
|
| ENCP1375-3 | 1375/1100 | 1250/1000 | 259 | 4012-46TWG2A | 1224 | 12 | 45.8 | E | 4795×2000×2525 | 8700 |
|
|
| ENCP1500-3 | 1500/1200 | 1350/1080 | 270 | 4012-46TWG3A | 1314 | 12 | 45.8 | E | 4795×2000×2525 | 9293 |
|
|
| ENCP1650-3 | 1650/1320 | 1500/1200 | 280 | 4012-46TWG4A | 1396 | 12 | 45.8 | E | 4795×2000×2525 | 9593 |
|
|
| ENCP1875-3 | 1875/1500 | 1710/1368 | 370 | 4012-46TAG3A | 1643 | 12 | 45.8 | E | 5065×2165×2565 | 13664 |
|
|
| ENCP2000-3 | 2000/1600 | 1850/1480 | 383 | 4016TAG1A | 1741 | 16 | 61.1 | E | 5725×2630×3150 | 13808 |
|
|
| ENCP2200-3 | 2200/1760 | 2000/1600 | 440 | 4016-61TRG2 | 1985 | 16 | 61.1 | E | 6020×2630×3125 | 14621 |
|
|
| ENCP2500-3 | 2500/2000 | 2250/1800 | 473 | 4016-61TRG3 | 2183 | 16 | 61.1 | E | 6020×2630×3125 | 14920 |
|
|
| GEUSETS | Specification | General specification | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 50HZ 230v/400v | ||||||||||||
| KVA/KW Cos 0.8 |
Cons 100% L/h |
Engine model | Max output | Cyl. |
displace ment |
Gov. | Open type dimension &weight | |||||
| ESP | PRP | KW | L | Dimenssion | weight | PDF download | ||||||
| LxWxH(mm) | kg | |||||||||||
| EUSP12-3 | 12/10 | 11/9 | 2.82 | 403D-11G | 11.8 | 3 | 1.13 | M | 1320×700×1160 | 440 |
|
|
| EUSP16-3 | 17/13 | 15/12 | 4.04 | 403A-15G2 | 10 | 3 | 1.13 | M | 1320×700×1160 | 480 |
|
|
| EUSP18-3 | 18/14 | 16/13 | 4.24 | 403D-15G | 16.2 | 3 | 1.5 | M | 1320×700×1160 | 520 |
|
|
| EUSP26-3 | 26/21 | 24/19 | 5.8 | 404D-22G | 24.3 | 4 | 2.2 | M | 1320×700×1160 | 580 |
|
|
| EUSP125-3 | 170/135 | 156/125 | 37.7 | 1106D-E66TAG2 | 161.6 | 6 | 6.6 | M | 2550×950×1535 | 1760 |
|
|
| EUSP132-3 | 180/144 | 163/130 | 38.7 | 1106D-E66TAG3 | 171.4 | 6 | 6.6 | M | 2550×950×1535 | 1800 |
|
|
| EUSP165-3 | 220/176 | 200/160 | 47.2 | 1106D-E66TAG4 | 204 | 6 | 6.6 | M | 2550×950×1535 | 1830 |
|
|
| EUSP170-3 | 250/200 | 231/185 | 52 | 1306A-E87TAG3 | 227 | 6 | 8.7 | M | 2550×950×1680 | 1879 |
|
|
| EUSP180-3 | 270/216 | 245/196 | 55.8 | 1306A-E87TAG4 | 242 | 6 | 8.7 | M | 2550×950×1680 | 1924 |
|
|
| EUSP220-3 | 220/176 | 200/160 | 47.2 | 1106D-E66TAG4 | 204 | 6 | 6.6 | M | 2550×950×1535 | 1830 |
|
|
| EUSP270-3 | 270/216 | 245/196 | 55.8 | 1306A-E87TAG4 | 242 | 6 | 8.7 | M | 2550×950×1680 | 1924 |
|
|
| EUSP250-3 | 250/200 | 231/185 | 52 | 1306A-E87TAG3 | 227 | 6 | 8.7 | M | 2550×950×1680 | 1879 |
|
|
| EUSP440-3 | 440/352 | 400/320 | 91 | 2206D-E13TAG2 | 406.5 | 6 | 12.5 | ECM | 3440×1150×1990 | 3345 |
|
|
| EUSP480-3 | 480/385 | 438/350 | 100 | 2206A-E13TAG6 | 461.7 | 6 | 12.5 | ECM | 3440×1150×1990 | 3375 |
|
|
| EUSP550-3 | 550/440 | 500/400 | 113 | 2506D-E15TAG1 | 514 | 6 | 15.1 | ECM | 3440×1150×1990 | 3800 |
|
|
| EUSP625-3 | 625/500 | 569/455 | 129.5 | 2506C-E15TAG3 | 568 | 6 | 15.1 | ECM | 3440×1150×1990 | 3693 |
|
|
| EUSP750-3 | 750/600 | 688/550 | 156.6 | 2506C-E15TAG4# | 623 | 6 | 15.1 | ECM | 3440×1150×1990 | 3770 |
|
|
| EUSP756-3 | 750/600 | 681/545 | 155 | 2806C-E18TAG3 | 678.2 | 6 | 18.1 | ECM | 3400×1540×1958 | 4339 |
|
|
